MANHOLES
Diamond Precast Concrete rated manholes meet MMCD Platinum [33 44 01] requirements:
1 - Designed by APEGBC P.Eng (Structural) for H-20 Roadway applications.
2 - Produced in Diamond Precast CSA A23.4 certified precast concrete facility Burnaby, B.C.
3 - CSA 3rd party verified to ATSM Standard C478M.
Item Code
Description
Details
Weight (#) Price/Per
MHR1
MHR2-36"
MHRS21
MHR2
MHR4
MHRS32
47
TBD
70
103
200
80
$ 22.00
Page 5 of 20
$ 80.00
$ 32.00
$ 22.00
$ 35.00
$ 40.20
Manhole Ring
Manhole Ring
Manhole Ring
Manhole Ring
Manhole Ring
Manhole Ring
Item Code
Description
Details
Weight (#) Price/Per
4209DLH
4206R
4224R
4224B
4209DL
4212R
4236R
4236B
750
310
1360
2360
910
668
2058
3000
$ 190.06
$ 105.00
$ 225.60
$ 411.00
4248B
3668
$ 594.00
42PBI
TBD
$ 825.00
42DHI
TBD
$ 625.00
$ 190.06
$ 112.50
$ 338.90
$ 524.30
EXT42
TBD
$ 215.00
42PBC
TBD
$ 625.00
Donut Lid
42"ID x 6"H Riser
42"ID x 24"H Riser
42"ID x 24"H Base
Donut Lid
42"ID x 12"H Riser
42"ID x 36"H Riser
42"ID x 36"H Base
4248B 42"ID x 48"H Base
42"ID Base
42"ID Overbuild
Extended Base
42"ID Base
1" Thickness (25" Clear Opening)
2" Thickness (36" Clear Opening) 'Telus' Style
2" to 1" Slope (25" Clear Opening)
2" Thickness (25" Clear Opening)
4" Thickness (25" Clear Opening)
3" to 2" Slope (25" Clear Opening)
* 42" Predl lined 10mm invert elevation (difference of 1% slope inlet and outlet) SDR 35 connection includes gasket.
Poured height varies.
** Prices starting at $625. Final price is determined by design requirements.
Manholes - 42”(1050mm)
Manhole Rings
Centered Hatch Opening (24" x 36") 9" height
Tongue Top & Groove Bottom
Tongue Top & Groove Bottom
Tongue Top
Offset Round Opening (25" Dia) 9" height
Tongue Top & Groove Bottom
Tongue Top & Groove Bottom
Tongue Top
Tongue Top
42" Stocked Pre bench configuration *
42" Doghouse style overbuild
Per Typical Requirements
42" Pre bench custom configuration **
