PRECAST CONCRETE &
MUNICIPAL CASTINGS
®
BOULEVARD & RESIDENTIAL PRODUCTS
LAWN BASINS & RISERS [Lawn Drains]
DRIVEWAY TRENCH [Trough]
Driveway Trench [TR-150]
48 x 7 x 6”ID [1200 x 175 x 150mm]
Driveway Trench End [TR-150END]
24 x 7 x 6”ID [600 x 175 x 150mm]
6” Grate for Trench [D624]
6 x 24 x 3/4”H [150 x 600 x 20mm]
PARKING CURBS
8 x 6 x 84”L [200 x 140 x 2100mm]
Poly-Encased
[Yellow, Green or Blue]
Concrete
6 x 5 x 72”L [150 x 130 x 1800mm]
METER BOXES [Service Boxes, Junction Boxes]
SUMP BASINS, RISERS & LIDS
12”ID [300mm]
Riser Heights
18”ID [450mm]
6” to 18” [150 - 450mm]
Base Height
6” to 24” [150 - 600mm]
18” [450mm]
24” [600mm]
Driveway Drain Box [DB-1212]
Driveway Drain Box and Grate Dimensions
13” x 13” x 12”H [350 x 350 x 300mm]
Grate for Driveway Box
11” x 11” x 3/4”H [250 x 250 x 20mm]
Lawn Basin
MB#37 6” [150mm]
12” [300mm]
Drain Sewer Water Storm
MB#66 8” [200mm]
12” [300mm]
Electric
MB#5686 7” [170mm]
15” [380mm]
Plain
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Remote
Reader Hole
Meter Box Height & Code
Cover Types
30”ID [750mm]
Lid Options
Lid Options
30” [750mm] or 30” Reduced to 24” [600mm]
36” [900mm] or 36” Reduced to 24” [600mm]
Riser Heights
6” [150mm] | 12“ [300mm] | 24” [600mm] | 36” [900mm]
Base Heights
36”ID [900mm]
Riser Heights
Base Heights
36” [900mm] | 42“ [1050mm] | 48” [1200mm]
No Ladder Rungs
With Ladder Rungs
30” or 36”
24”
Roadway Trench [TR-200] 48 x 8 x 8”ID [1200 x 200 x 200mm]
8” Grate for Trench [D824] 8 x 24 x 1”H [200 x 600 x 25mm]
www.
diamondprecast.comTR200 with D824 for Boulevard Applications Only [NOT Road Rated]
6” [150mm] | 12“ [300mm] | 24” [600mm] | 36” [900mm]
36” [900mm] | 42“ [1050mm] | 48” [1200mm]
